Aluminum Conductor XLPE Cable 3 Core 25mm² YJLV22 8.7/10kV Armored
Product Summary
Product Details
aluminum medium voltage power cable
,xlpe heavy aluminum cable
,xlpe medium voltage power cable
Product Description
Aluminum Conductor XLPE Cable 3 Core 25mm² YJLV22 8.7/10kV Armored
Cable Designation & Meaning
|
Code |
Meaning |
|---|---|
|
YJ |
XLPE (cross-linked polyethylene) insulation |
|
L |
Aluminium conductor (Al) |
|
V |
PVC inner bedding / outer sheath |
|
22 |
Steel tape armour (double steel tape, overlapping) + PVC sheath |
|
8.7/10 kV |
Rated voltage U₀/U = 8.7/10 kV; Uₘ = 12 kV |
|
8.7/15 kV |
Rated voltage U₀/U = 8.7/15 kV; Uₘ = 17.5 kV |
|
3×25 mm² |
Three power cores, each 25 mm² aluminium (3-core, no neutral, no PE) |
Construction: XLPE insulated, aluminium conductor, steel-tape armoured, PVC sheathed, three-core medium-voltage power cable.
Applicable Standards
- GB/T 12706.2-2020 / IEC 60502-2 — Power cables with extruded insulation and their accessories for rated voltages from 6 kV up to 30 kV
- GB/T 3956 / IEC 60228 — Conductors (Class 2 stranded circular, aluminium)
- GB/T 2951 / IEC 60811 — Insulating and sheathing materials — Common test methods
- GB/T 3048 — Test methods for electric cables
- GB/T 18380 / IEC 60332 — Flame retardant tests (Category C or B available)


YJLV22-3×25 mm² 8.7/10 kV (and 8.7/15 kV) — Cable Specification & Engineering Data
1. Product Overview & Rating Summary. YJLV22-3×25 is a compact medium-voltage (MV) power cable rated 8.7/10 kV (Um = 12 kV) at 50 Hz, built around three 25 mm² compacted-stranded ALUMINIUM conductors, each with a triple-extruded semi-conducting screen / XLPE insulation / semi-conducting screen system, a lapped copper-tape screen, and an overall double-galvanised-steel-tape armour (type 22) with a black PVC outer jacket. The "L" in YJLV22 distinguishes the aluminium conductor from the copper YJV22 — same insulation and armour system, but at roughly one-third the weight and one-third the conductor cost. The same construction is also manufactured in the 8.7/15 kV grade (Um = 17.5 kV) with thicker 5.5 mm XLPE insulation. The cable is designed for 10 kV distribution feeders serving 500–1000 kVA distribution transformers and small-to-medium MV motors in the 200–400 kW range. Finished diameter is about 55 mm (10 kV) and nominal mass about 2900 kg/km (≈ 290 kg per 100 m). With all three cores loaded, the cable carries about 95 A in free air at 25 °C (engineering estimate).
2. Layer-by-Layer Construction (Conductor to Outer Jacket).
| Layer | Construction | Wall | Diameter |
|---|---|---|---|
| Conductor (Al) ×3 | Compacted stranded annealed Al, Class 2 — 7×2.14 mm equivalent | — | ≈ 6.9 mm |
| Conductor screen | Extruded semi-conducting XLPE, co-extruded | ≈ 0.8 mm | ≈ 8.5 mm |
| XLPE insulation | Cross-linked polyethylene, triple-extruded | 4.5 mm (10 kV) / 5.5 mm (15 kV) | ≈ 18.1 / ≈ 20.1 mm |
| Insulation screen | Strippable semi-conducting XLPE | ≈ 0.8 mm | ≈ 19.7 / ≈ 21.7 mm |
| Copper-tape screen | 0.1 × 16 mm annealed Cu tape, lapped | ≈ 0.1 mm tape | ≈ 19.9 / ≈ 21.9 mm |
| Filler & bedding | PP/PE rope + non-woven binder | — | ≈ 48 / ≈ 51 mm bundle |
| Inner sheath | PVC/PE extruded bedding | ≈ 1.2 mm | ≈ 50 / ≈ 53 mm |
| Steel armour (type 22) | Double galvanised steel tape, helical lapped | 2 × 0.3 mm | ≈ 51 / ≈ 54 mm |
| PVC outer jacket | ST2 PVC, flame-retardant, black | 2.0 mm | ≈ 55 / ≈ 58 mm (finished) |
3. Electrical Characteristics. Each 25 mm² aluminium conductor is held to a maximum DC resistance of 1.20 Ω/km at 20 °C — about 60% higher than a copper conductor of the same cross-section, which is why aluminium cables are typically upsized one or two cross-section steps to match copper ampacity. Every length survives the routine 21.5 kV AC power-frequency proof held for five minutes (30.5 kV for the 15 kV grade). Partial discharge at 1.5 U0 must not exceed 20 pC. Dissipation factor tan δ ≤ 0.001 at U0. Insulation resistance ≥ 1000 MΩ·km, typical capacitance ≈ 0.55 μF/km. Impulse withstand (BIL) is 75 kV for the 10 kV grade and 95 kV for the 15 kV grade. With all three cores energised, reference loading is about 95 A in free air at 25 °C, about 90 A direct-buried.
Insulation Data
|
Property |
Value |
|---|---|
|
Material |
XLPE (cross-linked polyethylene) |
|
Nominal thickness |
4.5 mm |
|
Long-term service temp. |
90 °C |
|
Short-circuit temp. (≤5 s) |
250 °C (conductor limited; Al short-circuit rating is lower than Cu) |
|
Emergency overload temp. |
130 °C |
|
Routine test voltage (AC, 5 min) |
22 kV (8.7/10 kV); 30.5 kV (8.7/15 kV) |
|
Type-test voltage (AC) |
30 kV (8.7/10 kV); 45 kV (8.7/15 kV) |
|
Partial discharge test |
≤ 10 pC at 1.73 U₀ (15 kV) |
|
Tan δ (dissipation factor) |
≤ 0.004 at 20 °C |
Electrical Parameters
|
Parameter |
Value (8.7/10 kV) |
Value (8.7/15 kV) |
Note |
|---|---|---|---|
|
Rated voltage U₀/U |
8.7 / 10 kV |
8.7 / 15 kV |
— |
|
Max. system voltage Uₘ |
12 kV |
17.5 kV |
— |
|
Test voltage AC (5 min) |
22 kV |
30.5 kV |
Routine |
|
Type-test voltage |
30 kV |
45 kV |
— |
|
DC resistance @20 °C |
≤ 1.200 Ω/km |
≤ 1.200 Ω/km |
GB/T 3956 Class 2 Al max, 25 mm² |
|
AC resistance @90 °C (est.) |
≈ 1.53 Ω/km |
≈ 1.53 Ω/km |
per core |
|
Capacitance (approx.) |
≈ 0.22 µF/km |
≈ 0.22 µF/km |
per core to screen |
|
Inductive reactance (approx.) |
≈ 0.10 Ω/km |
≈ 0.10 Ω/km |
at 50 Hz, 3-core |
|
Current rating in air (30 °C) |
≈ 85 – 100 A |
≈ 85 – 100 A |
per core, 3-core (Al, limited by resistance) |
|
Current rating buried (20 °C) |
≈ 75 – 90 A |
≈ 75 – 90 A |
direct buried, 3-core |
|
Short-circuit current (1 s, Al, 250 °C) |
≈ 2.5 kA (2500 A) |
≈ 2.5 kA (2500 A) |
25 mm² Al |
|
Frequency |
50/60 Hz AC |
50/60 Hz AC |
— |
Reference values: 25 mm² Al at 90 A, 3-phase 10 kV → max balanced load ≈ 1.56 MVA. Voltage drop at 90 A ≈ 13.8 V/km per core (≈0.138% per 100 m) — significant voltage drop, consider larger size.
Temperature Characteristics
|
Property |
Value |
|---|---|
|
Max. conductor operating temp. |
90 °C (continuous) |
|
Max. short-circuit temp. (≤5 s) |
250 °C (Al conductor) |
|
Emergency overload temp. |
130 °C |
|
Min. installation ambient temp. |
0 °C (PVC sheath); below 0 °C pre-heating required |
|
Service ambient range |
−20 °C to +90 °C (with PVC sheath) |
|
Fire survival |
Standard (non-fire-rated); optional fire-resistant version available (ZC-YJLV22) |
4. Thermal Response & Flame Behaviour. XLPE insulation sustains a 90 °C continuous conductor temperature, with short-circuit capability up to 250 °C for ≤ 5 s. The cable is rated for service ambients between −20 and +50 °C. PVC jacket provides flame-retardant performance per GB/T 18380.34 class A. Short-circuit rating at 250 °C for 1 s is about 1.7 kA for the 25 mm² aluminium conductor — significantly lower than an equivalent copper core, so fault-current protection must be co-ordinated. Thermal resistance of reference burial soil is 1.2 K·m/W.
Fire Performance (YJLV22 — Standard)
|
Property |
Value / Requirement |
|---|---|
|
Flame retardant |
GB/T 18380.3 Category C (ZC), Category B (ZB) available |
|
Halogen content |
Contains halogen (PVC sheath) |
|
Smoke density |
Standard (non-low-smoke) |
|
Corrosivity |
Corrosive (PVC sheath) |
|
Fire survival (circuit integrity) |
Not applicable (standard version); use ZA-YJLV22 for flame-retardant A |
5. Installation Practice & Handling. Bends must not fall below 15 times the actual outer diameter — about 825 mm for this size. The steel armour must be earthed at both ends; the copper-tape screen must be bonded per MV practice. Critically, the aluminium conductors must be terminated with bimetallic Al-Cu lugs — direct contact between aluminium and copper in the presence of moisture causes galvanic corrosion and joint failure. MV heat-shrink or cold-shrink termination kits are mandatory. Laying temperature must not fall below 0 °C. At about 290 kg per 100 m, this lightweight cable can be man-handled on site, but the softer aluminium conductor is more prone to kinking — avoid tight pulls and ensure proper drum rotation.
Mechanical & Installation Parameters
|
Parameter |
Value |
Remarks |
|---|---|---|
|
Minimum bending radius |
≥ 15 × OD → ≈ 683 mm at Ø45.5 mm |
static installation |
|
Max. pulling tension |
1500 N |
Al conductor has lower tensile strength than Cu; use proper grips |
|
Direct burial |
Suitable |
steel tape armour provides mechanical protection |
|
Conduit ID |
≥ 1.5 × OD → ≥ 69 mm; use 75 mm or 80 mm |
— |
|
Fixing |
cable clamps, steel straps |
— |
|
Impact resistance |
High |
steel tape armour absorbs mechanical shock |
|
Water resistance |
Moisture-resistant (PVC sheath + inner bedding) |
not fully watertight |
|
Armour type |
Double steel tape, overlapping |
galvanized or mill finish |
|
Armour short-circuit rating |
≈ 5 kA (1 s, steel tape) |
— |
|
Termination note |
Al conductors require Al-compatible lugs (bimetallic or Al-Cu transition) |
critical for installation |
6. Typical Service Applications. This YJLV22-3×25 aluminium MV cable is the cost-effective choice for 10 kV / 15 kV distribution feeders where mechanical strength and burial protection are needed but the load is moderate: 500–1000 kVA distribution transformer primary feeds in suburban and rural networks, 10 kV branch feeds to small industrial plants and workshops, MV motor branch feeds for motors in the 200–400 kW range (small pumps, fans, compressors), township and rural 10 kV overhead-to-underground transition feeders, residential-commercial estate 10 kV incoming mains, municipal lighting and water-supply 10 kV supply lines, small PV / solar-farm 10 kV collection laterals, mining auxiliary 10 kV power supplies, and any circuit where the lightweight aluminium conductor reduces installation and support-structure costs relative to copper. Approved installation methods include direct burial, cable tray, concrete duct, and indoor MV cable trench.

7. Testing & Quality Assurance Regime. Routine tests on every length include conductor DC resistance ≤ 1.20 Ω/km at 20 °C, the 21.5 kV AC / 5 min withstand (30.5 kV for 15 kV grade), partial discharge ≤ 20 pC at 1.5 U0, tan δ ≤ 0.001, insulation resistance ≥ 1000 MΩ·km, conductor continuity across all three cores, steel-armour and copper-screen continuity, and dimensional inspection. Sample and type tests comprise impulse withstand at ±75 kV (or ±95 kV for 15 kV), heating-cycle load-loss test, bending at 15 × OD, short-circuit to 250 °C, flame spread GB/T 18380.34 class A, and voltage re-test after thermal ageing. A factory test certificate accompanies each drum.
Cable Parameters
| YJLV22-3×25 mm² 8.7/10 kV (and 8.7/15 kV variant) — Full Parameter Sheet | ||||
| Medium-voltage power cable · ALUMINIUM conductor / XLPE insulation / copper-tape screen / double-steel-tape armour (type 22) / PVC outer sheath · per GB/T 12706.2 · 3 cores · finished Ø ≈ 55 mm (10 kV) / ≈ 58 mm (15 kV) | ||||
| Section | Parameter | Value | Unit | Remarks / Standard |
| 01 · Identification | ||||
| Cable type | YJLV22 | — | Al conductor / XLPE insulation / double-steel-tape armour / PVC outer sheath | |
| Rated voltage (U0/U) | 8.7/10 | kV | AC 50 Hz; Um = 12 kV (10 kV grade) | |
| Alternative voltage grade | 8.7/15 | kV | AC 50 Hz; Um = 17.5 kV (15 kV grade) — thicker XLPE | |
| Number of cores | 3 × 25 | — | 3 phase cores (25 mm²) — no separate neutral in MV cable | |
| Conductor material | Compacted stranded ALUMINIUM | — | Class 2 stranded per GB/T 3956; lighter, lower cost than Cu | |
| Conductor screen | Extruded semi-conducting XLPE | — | Conductor screen layer (radial field control) | |
| Insulation material | Cross-linked polyethylene (XLPE) | — | 90 °C continuous, 250 °C short-circuit | |
| Insulation screen | Extruded semi-conducting, strippable | — | Outer screen layer | |
| Metallic screen | Copper tape, lapped | — | 0.1 × 16 mm Cu tape; equipotential earth | |
| Armour | Double galvanised steel tape | — | Type 22 armour — mechanical protection | |
| Outer sheath | PVC (ST2), flame-retardant | — | UV- and abrasion-resistant | |
| Standard reference | GB/T 12706.2 / IEC 60502-2; GB/T 3956 | — | Medium-voltage power cables 1.8/3 kV to 26/35 kV | |
| 02 · Conductor (Aluminium) | ||||
| Stranding — 25 mm² | Compacted stranded aluminium | — | Class 2, circular compacted | |
| Strand count (typical) | 7 × 2.14 mm (or equivalent) | — | Compacted after stranding | |
| Conductor diameter | ≈ 6.9 | mm | After compacting (est.) | |
| DC resistance @ 20 °C | ≤ 1.20 | Ω/km | Maximum per GB/T 3956 Class 2 (Al) | |
| AC resistance @ 50 Hz (≈ 90 °C) | ≈ 1.7 | Ω/km | Skin/proximity effect included | |
| Conductor screen thickness | ≈ 0.8 | mm | Extruded semi-conducting layer | |
| Conductor weight per km | ≈ 68 | kg/km | Aluminium density 2.70 g/cm³ | |
| 03 · Insulation | ||||
| Insulation type | Cross-linked polyethylene (XLPE) | — | Extruded, triple-layer co-extrusion | |
| Insulation thickness — 8.7/10 kV | 4.5 | mm | Nominal, per GB/T 12706.2 | |
| Insulation thickness — 8.7/15 kV | 5.5 | mm | Thicker for 15 kV grade | |
| Core Ø over insulation — 10 kV | ≈ 18.1 | mm | 6.9 + 2×(0.8+4.5+0.8) | |
| Core Ø over insulation screen — 15 kV | ≈ 20.1 | mm | 6.9 + 2×(0.8+5.5+0.8) | |
| Insulation screen thickness | ≈ 0.8 | mm | Strippable semi-conducting | |
| Impulse withstand (BIL) — 10 kV | 75 | kV | Lightning impulse test | |
| Impulse withstand (BIL) — 15 kV | 95 | kV | Lightning impulse test | |
| 04 · Metallic Screen & Filler | ||||
| Screen material | Annealed copper tape | — | Lapped with overlap | |
| Screen tape dimensions | 0.1 × 16 | mm | Two layers lapped (typical) | |
| Screen function | Equipotential earth / fault-current path | — | Earthed at terminations | |
| Filler material | PP / jute rope, flame-retardant | — | Fills interstices for round cable | |
| Bedding / binder tape | Semi-conducting or non-woven tape | — | Holds bundle; anti-corrosion layer | |
| Assembled bundle Ø — 10 kV | ≈ 48 | mm | Before inner sheath (est.) | |
| Assembled bundle Ø — 15 kV | ≈ 51 | mm | Before inner sheath (est.) | |
| 05 · Inner Sheath & Armour | ||||
| Inner sheath / bedding | PVC or PE extruded | — | Corrosion barrier under armour | |
| Inner sheath thickness | ≈ 1.2 | mm | Over bundle | |
| Armour type | Double steel tape (type 22) | — | Double-tape helical armour | |
| Armour tape thickness | 2 × 0.3 | mm | Galvanised steel, lapped | |
| Armour function | Mechanical protection against crush / impact | — | Permits direct burial / tray | |
| Armour diameter — 10 kV | ≈ 51 | mm | Over inner sheath (est.) | |
| 06 · Outer Sheath | ||||
| Jacket material | PVC, ST2, flame-retardant | — | GB/T 12706.1 | |
| Jacket thickness | 2 | mm | Minimum over armour | |
| Overall finished diameter — 10 kV | ≈ 55 | mm | Cross-referenced industry sample | |
| Overall finished diameter — 15 kV | ≈ 58 | mm | Thicker insulation version | |
| Approx. cable mass — 10 kV | ≈ 2900 | kg/km | Al + XLPE + steel + PVC (much lighter than Cu) | |
| Approx. cable mass — 15 kV | ≈ 3050 | kg/km | Heavier due to thicker insulation | |
| Jacket colour | Black (standard) | — | UV-resistant carbon-black PVC | |
| Mass per 100 m — 10 kV | ≈ 290 | kg/100 m | For drum loading | |
| 07 · Electrical | ||||
| Rated voltage U0/U | 8.7/10 | kV | AC 50 Hz; Um = 12 kV | |
| Maximum system voltage Um (10 kV) | 12 | kV | — | |
| DC resistance @ 20 °C | ≤ 1.20 | Ω/km | 25 mm² Al Class 2 | |
| Insulation resistance | ≥ 1000 | MΩ·km | XLPE at 20 °C | |
| Capacitance (typical) | ≈ 0.55 | μF/km | Per core (est.) | |
| Dissipation factor tan δ (at U0) | ≤ 0.001 | — | XLPE, 20 °C | |
| Routine test voltage (AC) — 10 kV | 21.5 kV / 5 min | — | Power-frequency withstand | |
| Routine test voltage (AC) — 15 kV | 30.5 kV / 5 min | — | Power-frequency withstand | |
| Air ampacity @ 25 °C | ≈ 95 | A | 3 cores loaded, Al, in free air (est.) | |
| Buried ampacity @ 25 °C soil | ≈ 90 | A | 3 cores loaded, Al, direct burial (est.) | |
| 08 · Thermal & Fire | ||||
| Max continuous conductor temp. | 90 | °C | Normal service | |
| Short-circuit temp. (≤ 5 s) | 250 | °C | XLPE limit | |
| Fire behaviour | Flame-retardant (PVC jacket) | — | GB/T 18380.34 class A | |
| Service ambient range | −20 to +50 | °C | Fixed installation | |
| Thermal resistance (soil) | 1.2 | K·m/W | Reference burial conditions | |
| Short-circuit rating (1 s) | ≈ 1.7 | kA | 25 mm² Al at 250 °C | |
| 09 · Installation | ||||
| Min bending radius | ≥ 15 × OD ≈ 825 | mm | Fixed installation (armoured) | |
| Laying temperature | ≥ 0 | °C | Pre-heat below 0 °C | |
| Laying methods | Tray, direct burial, conduit, duct | — | Armour permits direct burial | |
| Armour earthing | Both ends earthed | — | Steel armour must be earthed | |
| Copper screen earthing | At both ends (or single point for cross-bonding) | — | MV cable screen bonding | |
| Termination / joints | Al-Cu transition lugs required | — | Al conductor — use bimetallic lugs to avoid galvanic corrosion | |
| Special tools | Cable cutter, crimping tool, torque wrench | — | MV lugs required | |
| 10 · Packing | ||||
| Standard supply length | 500 or 1000 | m/drum | Custom cut lengths available | |
| Reel / packing type | Wooden-steel drum | — | Sealed ends against moisture | |
| Surface marking | YJLV22, 8.7/10 kV, 3×25, supplier, year, metre marks | — | Per GB/T 6995 | |
| Storage conditions | Dry, covered, −20 to +40 °C | — | Sealed ends; protect from UV | |
| Transport | Drums secured against rolling | — | Light cable, easy to handle | |
Cable Test Parameters
| Test Parameters — YJLV22-3×25 mm² 8.7/10 kV (and 8.7/15 kV) | ||||
| No. | Test Item | Test Condition / Method | Requirement | Type |
| 1 | Conductor DC resistance | GB/T 3048.4, 20 °C | ≤ 1.20 Ω/km (25 mm² Al) | Routine |
| 2 | Power-frequency withstand (routine) | 21.5 kV AC, 5 min (10 kV grade) | No breakdown | Routine |
| 3 | Power-frequency withstand (15 kV grade) | 30.5 kV AC, 5 min | No breakdown | Routine |
| 4 | Partial discharge test | At 1.5 U0 = 13 kV (10 kV grade) | ≤ 20 pC at 1.73 U0 | Routine |
| 5 | Dissipation factor tan δ | At U0, 20 °C | tan δ ≤ 0.001 | Routine |
| 6 | Insulation resistance | GB/T 3048.5 | ≥ 1000 MΩ·km | Routine |
| 7 | Dimensional check | Micrometer / micrometer microscope | Insulation ≥ 4.5 mm (10 kV); jacket ≥ 2.0 mm | Routine |
| 8 | Impulse voltage test (BIL) | ±75 kV, 10 impulses (10 kV grade) | No breakdown at 75 kV | Type |
| 9 | Impulse voltage test (15 kV grade) | ±95 kV, 10 impulses | No breakdown at 95 kV | Type |
| 10 | Heating cycle / load loss | 3 cycles U0 + rated current | No damage; tan δ stable | Type |
| 11 | Bending test | 15 × OD mandrel, 3 cycles | No damage to insulation or sheath | Type |
| 12 | Short-circuit temperature test | 250 °C, 5 s equivalent | No insulation collapse | Type |
| 13 | Flame propagation | GB/T 18380.34 class A | No vertical flame spread | Type |
| 14 | Sheath / armour continuity | Continuity meter | Steel armour and Cu tape continuous | Routine |
| 15 | Voltage test after ageing | After thermal ageing cycle | Withstands 2.5 U0 AC | Type |
| 16 | Marking legibility | Visual + rubbing | YJLV22 / 8.7/10 kV / 3×25 / metre marks legible | Routine |
Cable Cross Section Structure

| YJLV22-3×25 mm² 8.7/10 kV — Cross-Section Construction Diagram (Schematic) | |||||
| MV layered build-up: ALUMINIUM conductor → conductor screen → XLPE insulation → insulation screen → Cu-tape screen → filler → bedding → double-steel-tape armour → PVC jacket · 8.7/10 kV (8.7/15 kV variant noted) · finished Ø ≈ 55 mm | |||||
| No. | Layer | Material / Construction | Nominal Thickness (mm) | Diameter (mm) | Function / Remarks |
| 1 | Conductor (Al) ×3 | Compacted stranded ALUMINIUM, Class 2 — 7×2.14 mm equivalent per core | — | ≈ 6.9 | Power conductor; R ≤ 1.20 Ω/km at 20 °C |
| 2 | Conductor screen | Extruded semi-conducting XLPE, co-extruded with insulation | ≈ 0.8 | ≈ 8.5 | Eliminates air gaps; smooth radial field |
| 3 | XLPE insulation | Cross-linked polyethylene, triple-layer co-extrusion | 4.5 (10 kV) / 5.5 (15 kV) | ≈ 18.1 / ≈ 20.1 | Main dielectric; 90 °C continuous |
| 4 | Insulation screen | Strippable semi-conducting XLPE | ≈ 0.8 | ≈ 19.7 / ≈ 21.7 | Outer screen; equipotential |
| 5 | Copper-tape screen | Annealed Cu tape, lapped, 0.1 × 16 mm | ≈ 0.1 tape | ≈ 19.9 / ≈ 21.9 | Earth path / fault-current return |
| 6 | Filler & bedding | PP/PE rope filler + non-woven binder tape | — | ≈ 48 / ≈ 51 bundle | Round shape; anti-corrosion bedding |
| 7 | Inner sheath | PVC/PE extruded bedding over bundle | ≈ 1.2 | ≈ 50 / ≈ 53 | Corrosion barrier under armour |
| 8 | Steel armour (type 22) | Double galvanised steel tape, helically lapped | 2 × 0.3 | ≈ 51 / ≈ 54 | Mechanical crush / impact protection |
| 9 | PVC outer jacket | ST2 PVC, flame-retardant, black | 2.0 | ≈ 55 / ≈ 58 (finished) | UV, abrasion and chemical protection |
| Key Dimensions & Properties (expanded) | |||||
| Finished cable diameter (10 kV) | ≈ 55 | mm | Cross-referenced industry sample | ||
| Finished cable diameter (15 kV) | ≈ 58 | mm | Thicker XLPE variant | ||
| Approx. cable mass (10 kV) | ≈ 2900 | kg/km | Al + XLPE + steel + PVC (lightweight) | ||
| Approx. cable mass (15 kV) | ≈ 3050 | kg/km | Heavier due to thicker insulation | ||
| Nominal voltage rating | 8.7/10 | kV | AC 50 Hz; Um = 12 kV | ||
| Alternative voltage grade | 8.7/15 | kV | Um = 17.5 kV; 5.5 mm XLPE | ||
| Max continuous conductor temp. | 90 | °C | Normal service | ||
| Short-circuit temp. (≤5 s) | 250 | °C | XLPE limit | ||
| Impulse withstand (BIL) | 75 (10 kV) / 95 (15 kV) | kV | Lightning impulse | ||
| Min bending radius | ≥ 15 × OD ≈ 825 | mm | Fixed installation | ||
| DC resistance @ 20 °C | ≤ 1.20 | Ω/km | 25 mm² Al | ||
| Insulation resistance | ≥ 1000 | MΩ·km | XLPE | ||
| Routine test voltage | 21.5 kV AC / 5 min | — | 10 kV grade; 30.5 kV for 15 kV | ||
| Air ampacity @ 25 °C | ≈ 95 | A | 3 cores loaded, Al (est.) | ||
| Mass per 100 m (10 kV) | ≈ 290 | kg/100 m | For drum loading | ||
| Schematic — not to exact scale. Finished Ø ≈ 55 mm (10 kV) and weight ≈ 2900 kg/km from cross-referenced industry samples; conductor/insulation diameters per GB/T 12706.2 and GB/T 3956; ampacity 95 A is an engineering estimate for ALUMINIUM conductors. The 8.7/15 kV variant uses 5.5 mm XLPE insulation, ≈ 58 mm OD and ≈ 3050 kg/km. Values marked (est.) require confirmation against the factory test certificate. Al conductors require bimetallic Al-Cu lugs at terminations. | |||||
Cable Construction Description
| Construction Description — YJLV22-3×25 mm² 8.7/10 kV | |||
| Layer-by-layer MV build-up narrative · 8.7/10 kV (and 8.7/15 kV variant) · ALUMINIUM / triple-extruded XLPE / Cu-tape screen / double-steel-tape armour / PVC jacket · finished Ø ≈ 55 mm | |||
| 1. Product Identity & Ratings | |||
| YJLV22-3×25 is a compact medium-voltage (MV) power cable rated 8.7/10 kV (Um = 12 kV) at 50 Hz, built around three 25 mm² compacted-stranded ALUMINIUM conductors, each with a triple-extruded semi-conducting screen / XLPE insulation / semi-conducting screen system, a lapped copper-tape screen, and an overall double-galvanised-steel-tape armour (type 22) with a black PVC outer jacket. The 'L' in YJLV22 distinguishes the aluminium conductor from copper (YJV22). The same construction is also manufactured in the 8.7/15 kV grade (Um = 17.5 kV) with thicker 5.5 mm XLPE insulation. The cable is designed for 10 kV distribution feeders serving 500–1000 kVA distribution transformers and small-to-medium MV motors in the 200–400 kW range. Finished diameter is about 55 mm (10 kV) and nominal mass about 2900 kg/km (≈ 290 kg per 100 m). With all three cores loaded, the cable carries about 95 A in free air at 25 °C (engineering estimate). | |||
| 2. Aluminium Conductor & Screens | |||
| Each 25 mm² conductor is compacted-stranded aluminium (Class 2), with a strand-lay diameter of about 6.9 mm and DC resistance ≤ 1.20 Ω/km at 20 °C. Aluminium is roughly one-third the weight of copper and one-third the cost, but it has roughly 60% lower conductivity — hence the larger cross-section needed for a given current. A semi-conducting conductor screen (≈ 0.8 mm) is co-extruded directly over the aluminium to eliminate air gaps and smooth the electric field. The conductor screen bonds electrically to the aluminium. | |||
| 3. XLPE Insulation | |||
| Cross-linked polyethylene (XLPE) is extruded in a triple-layer co-extrusion process: conductor screen → XLPE insulation → insulation screen, all in one pass to avoid contamination. For the 8.7/10 kV grade the insulation thickness is 4.5 mm; for the 8.7/15 kV grade it is 5.5 mm. XLPE sustains 90 °C continuous conductor temperature and 250 °C short-circuit for ≤ 5 s. The outer insulation screen is strippable for termination work. Over the insulation screen a 0.1 × 16 mm copper tape is lapped to provide an equipotential earth and fault-current return path. | |||
| 4. Bedding, Steel Armour & PVC Jacket | |||
| Three screened cores are cabled round with PP/PE rope filler and a non-woven binder tape, giving a bundle of about 48 mm (10 kV). A PVC/PE inner bedding (≈ 1.2 mm) is extruded over the bundle, then a double layer of 0.3 mm galvanised steel tape is helically lapped — this is the type-22 armour that protects against crush and impact and permits direct burial. Finally a 2.0 mm black PVC (ST2) outer jacket is extruded over the armour to the ≈ 55 mm finish, providing UV, abrasion and chemical resistance. | |||
| 5. Site Handling & Operational Notes | |||
| • Observe the 15 × OD minimum bending radius (≈ 825 mm). • The steel armour must be earthed at both ends; the copper-tape screen must be bonded per MV practice. • Use bimetallic Al-Cu lugs at all terminations — direct Al-to-Cu contact causes galvanic corrosion. • Service ambient −20 to +50 °C; conductor up to 90 °C continuous. • Routine test 21.5 kV AC / 5 min (10 kV); impulse withstand 75 kV. • At ≈ 290 kg/100 m, this light cable is easy to man-handle on site, but avoid kinking the flexible Al conductor. |
8. Factory Advantages

9. Packaging, Storage & Logistics. Standard delivery is 500 m or 1000 m per wooden-steel drum, with bespoke cut lengths available on request. Each drum carries type (YJLV22), voltage, size, supplier identity, production year and sequential metre marking per GB/T 6995. Storage should be in dry, covered premises at −20 to +40 °C, shielded from direct sunlight and moisture; drum end seals must remain intact until installation. MV cable terminations and joints should be scheduled immediately after laying to avoid prolonged exposure of the cut aluminium ends.

10. Procurement Specification. State "YJLV22-8.7/10 kV-3×25" (or "YJLV22-8.7/15 kV-3×25" for the thicker-insulation grade) together with the required length or drum arrangement. Always order bimetallic Al-Cu lugs and MV termination kits at both ends — do not substitute pure copper lugs on aluminium conductors. Always request the factory test certificate, which must include the partial-discharge and impulse-withstand reports, to confirm the actual diameter, weight and conductor resistances for the production batch.
11. Cable Industry FAQ.
- Q1: Why choose aluminium (YJLV22) over copper (YJV22)? Aluminium costs roughly one-third of copper per metre at the same cross-section and weighs roughly one-third, which reduces both material cost and installation labour for long MV runs. The trade-off is higher resistance — for the same ampacity you typically need to upsize by one or two cross-section steps. For lightly-loaded rural or suburban distribution feeders, YJLV22 is the standard cost-optimised choice.
- Q2: What does the "L" in YJLV22 mean? "L" = aluminium conductor. Without the L, YJV22 uses copper. The "22" still means double-steel-tape armour over PVC jacket — identical mechanical and fire protection.
- Q3: Why must I use bimetallic lugs? Aluminium and copper form a galvanic cell when directly connected in the presence of moisture. Over years this corrodes the aluminium at the joint, increasing resistance and eventually overheating. Bimetallic Al-Cu lugs have an aluminium barrel on the conductor side and a copper flange on the equipment side, isolating the two metals.
- Q4: How does 3×25 Al compare to 3×25 Cu in ampacity? At 25 mm², the aluminium version carries about 95 A in free air versus about 120 A for copper — roughly 25% less. To match 120 A you would typically choose a 35 or 50 mm² aluminium cable.
- Q5: When do I choose 8.7/10 kV vs 8.7/15 kV? Choose 8.7/10 kV for nominal 10 kV distribution networks (Um = 12 kV). Choose 8.7/15 kV for nominal 15 kV networks (Um = 17.5 kV) or where the system may be up-rated — the thicker 5.5 mm XLPE gives a larger safety margin.
- Q6: Why is there no separate neutral core? At MV distribution voltages, three-phase currents are balanced and the system is typically solidly or resistance-earthed; the copper-tape screen provides the earth path. A separate neutral is not required in standard 3-core MV construction.
- Q7: Can this cable be directly buried? Yes — the double-steel-tape armour provides crush protection, and the PVC jacket is moisture-resistant. Direct burial depth and covering must follow the local MV cable installation code.
- Q8: What is partial discharge and why is it tested? Partial discharge (PD) is tiny electrical sparks inside the insulation caused by voids or contaminants. At 1.5 U0, PD must be ≤ 20 pC. High PD values predict early insulation failure and are the most sensitive factory-quality indicator.
- Q9: Why is the routine test 21.5 kV and not 10 kV? Routine tests apply a power-frequency withstand voltage higher than the rated voltage (typically 2.5 U0 = 21.75 kV, rounded to 21.5 kV) to catch manufacturing defects before site installation.
- Q10: Is the short-circuit rating adequate? At 25 mm² aluminium, the 1 s short-circuit rating is about 1.7 kA — much lower than copper because of aluminium's lower melt point and higher resistance. Protection devices (fuses, breakers) must be sized to clear faults below this level; for high-fault-level networks, upsizing to 35 or 50 mm² aluminium is recommended.
- Q11: What service life can be expected? When installed, terminated and operated within the stated temperature, voltage and current ratings, XLPE-insulated MV cables — aluminium or copper — are designed for a service life of around 30 years in fixed installation. The dominant failure mode is moisture or PD at terminations, so professional jointing and proper bimetallic lugs are critical.
