2x35mm2 2 Cores Cable Stranded Copper Low Voltage Power Cable ZR Grade

2x35mm2 2 Cores Cable Stranded Copper Low Voltage Power Cable ZR Grade

Basic Properties

country of origin
China
brand name
TD
certificate
CE/ISO/CCC
product model
ZR-YJV 2*35mm²

Trading Properties

moq
1 Meter
payment method
L/C,T/T
supply capacity
10000 meters per month

Product Summary

ZR-YJV 2*35mm² Flame Retardant 2 Core Cable, 0.6/1kV Stranded Copper, XLPE Insulation PVC Jacket for Construction Power Code Mean:ZR-Flame Retardant,YJ-XLPE Insulation,V-PVC Jacket ZR-YJV 2×35 mm² — Technical Data Review 1. Product Summary. ZR-YJV 2×35 is a two-core flame-retardant power cable — ...

Product Details

Highlight:

2x35mm2 2 Core Cable

,

Stranded Copper 2 Core Cable

,

ZR grade Low Voltage Power Cable

Conductor (×2):
Bare Annealed Copper, Class 2 Stranded, 7×∅2.52 Mm, Conductor Ø ≈ 7.5 Mm
Conductor nominal area:
35 Mm²
Number of cores:
2
Conductor construction:
Class 2, 7×∅2.52 Mm Min. 7 Wires
Conductor diameter (approx.):
7.5mm
Insulation (×2):
XLPE
Insulation thickness:
0.9 Mm (35 Mm² Class)
Diameter over insulated core:
9.3 Mm(7.5 + 2×0.9)
Filler / binder:
FR PP Filler + FR Tape
Outer sheath:
Flame-retardant PVC (ZR Grade)
Sheath thickness:
1.8 Mm (multi-core Rule, ≥1.8 Mm)
Overall cable diameter:
20.5 – 21.5 Mm,use 21.0 Mm For Design
Approx. weight:
580 – 650 Kg/km,use ≈ 615 Kg/km
Long-term service temp.:
90 °C
Short-circuit temp. (≤5 s):
250 °C
Emergency overload:
105–130 °C
Routine test:
3.5 KV AC / 5 Min; Type Test 4.0 KV
Volume resistivity @90 °C:
≥ 10¹² Ω·cm

Product Description

ZR-YJV 2*35mm² Flame Retardant 2 Core Cable, 0.6/1kV Stranded Copper, XLPE Insulation PVC Jacket for Construction Power



Code Mean:ZR-Flame Retardant,YJ-XLPE Insulation,V-PVC Jacket

ZR-YJV 2×35 mm² — Technical Data Review

1. Product Summary. ZR-YJV 2×35 is a two-core flame-retardant power cable — twin 35 mm² copper conductors, XLPE insulation, PVC sheath, rated 0.6/1 kV (Um = 1.2 kV), 50 Hz. It conforms to GB/T 12706.1 / IEC 60502-1, GB/T 3956 / IEC 60228 (core) and GB/T 19666 / GB/T 18380 (fire, default ZC).



2x35mm2 2 Cores Cable Stranded Copper Low Voltage Power Cable ZR Grade



2. Construction Overview. Core-to-jacket stack:

Layer Build Wall Diameter
Conductor (×2) Annealed copper, Class 2, 7 × 2.52 mm (7/2.52) each, 35 mm² per core — ≈ 7.5 mm per core
Insulation (×2) Cross-linked polyethylene 0.9 mm ≈ 9.3 mm per core (over ins.)
Lay-up Two cores + non-hygroscopic filler, optional binder tape — ≈ 18.6 mm
Sheath Flame-retarded PVC, ST2, black 1.8 mm ≈ 22.0 mm overall

Weight ≈ 868 kg/km (Al version ≈ 413).



3. Electrical Ratings. DC resistance ≤ 0.524 Ω/km per core @ 20 °C; routine 3.5 kV / 5 min; XLPE volume resistivity ≥ 1×10¹² Ω·cm; typical insulation resistance ≥ 36.7 MΩ·km; capacitance ≤ 0.45 μF/km per core. Reference ampacity (both cores loaded) ≈ 185 A in air (30 °C) and ≈ 231 A direct-buried (20 °C) per Chengtantai; Mingda's armored YJV22 table quotes 140 A @25 °C — derate per GB/T 16895 / IEC 60364.



Parameter

Value

Note

Rated voltage U₀/U

0.6 / 1 kV

Uₘ = 1.2 kV

Test voltage AC (5 min)

3.5 kV

Routine

Type-test voltage

4.0 kV

IEC 60502

DC resistance @20 °C (Class 2 Cu, per core)

≤ 0.524 Ω/km

GB/T 3956 max

AC resistance @90 °C (est.)

≈ 0.681 Ω/km

per core

Current rating in air (30 °C, single circuit, 2-core)

≈ 105 – 115 A

design ≈ 110 A

Direct buried (20 °C, soil 1.0 K·m/W, 0.7 m)

≈ 130 – 145 A

design ≈ 138 A

Short-circuit current (1 s, Cu, 250 °C, per core)

≈ 3.50 kA

reference

Frequency

50/60 Hz AC (DC usable)

—



4. Thermal & Bending & Test data. Continuous 90 °C; short-circuit 250 °C (≤ 5 s); ambient −20 to +45 °C; laying ≥ 0 °C; minimum bend radius ≥ 15 × OD (multi-core).



ZR-YJV 2×35 mm² Flame-Retardant Copper-Conductor XLPE-Insulated PVC-Sheathed Power Cable — Product Parameters (0.6/1 kV, Two-Core)
Construction: CU / XLPE / PVC, 2 cores  •  Standards: GB/T 12706.1, IEC 60502-1 (cable), GB/T 3956 (conductor), GB/T 19666 & GB/T 18380 (flame retardance)  •  Nominal values for reference — confirm against factory test certificate
No. Category Parameter Value Unit Notes / Standard Reference
A. Product Identification
1 Identification Product name Flame-retardant copper-conductor XLPE-insulated PVC-sheathed power cable (two-core) — Designation ZR-YJV; "ZR" = flame-retardant (halogen-containing)
2 Identification Model designation ZR-YJV 2×35 — 2 cores × 35 mm²; Cu / XLPE / PVC
3 Identification Design standards GB/T 12706.1; IEC 60502-1 — Conductor: GB/T 3956 / IEC 60228; flame retardance: GB/T 19666, GB/T 18380
4 Identification Rated voltage U0/U 0.6/1 kV Max system voltage Um = 1.2 kV
5 Identification Rated frequency 50 Hz AC power distribution
6 Identification Number of cores 2 — Two-core cable; phase + neutral (L+N) duty
7 Identification Nominal cross-sectional area 35 mm² Per core; nominal cross-section per GB/T 3956
B. Cable Construction (from conductor to outer sheath)
8 Conductor Material Plain annealed copper (Cu) — High-conductivity electrolytic / oxygen-free copper
9 Conductor Conductor class Class 1 or Class 2 (typical: Class 2, stranded) — GB/T 3956 / IEC 60228
10 Conductor Typical stranding construction (per core) 7 wires × 2.52 mm (7/2.52) — Class 2 round stranded; nominal section 35 mm² per core
11 Conductor Conductor diameter (per core) ≈ 7.5 mm Ø of the 7/2.52 stranded core (7.0–7.5 mm across practice)
12 Conductor Max. DC resistance of conductor at 20 °C 0.524 Ω/km GB/T 3956, Class 2 copper; acceptance criterion for 35 mm²
13 Insulation Material Cross-linked polyethylene (XLPE) — Thermally cross-linked; natural/transparent colour
14 Insulation Nominal insulation thickness 0.9 mm GB/T 12706.1 / IEC 60502-1 (0.6/1 kV, 35 mm²)
15 Insulation Diameter over insulation (per core) ≈ 9.3 mm ≈ 7.5 + 2 × 0.9 (calculated)
16 Lay-up Core assembly Two insulated cores laid up with non-hygroscopic filler; optional binder tape — Round construction, right-hand lay
17 Sheath Material Flame-retardant polyvinyl chloride (PVC, ST2 type) — Colour: black (or as ordered)
18 Sheath Nominal sheath thickness 1.8 mm GB/T 12706.1 / IEC 60502-1 (ahtk table)
19 Dimensions Approx. overall diameter 22.0 mm ahtk 22.0 (unarmored); armored YJV22 2×35 ≈ 24.9 mm
20 Dimensions Approx. cable weight ≈ 868 kg/km ahtk 868 (aluminium version ≈ 413 kg/km); armored YJV22 2×35 ≈ 1099 kg/km
C. Electrical Performance
21 Electrical Max. DC conductor resistance at 20 °C 0.524 Ω/km GB/T 3956; routine measurement
22 Electrical Power-frequency withstand voltage (routine test) 3.5 kV / 5 min, no breakdown — AC 50 Hz; per GB/T 12706.1 / IEC 60502-1
23 Electrical Insulation resistance (finished cable, 20 °C) ≥ 36.7 MΩ·km Typical finished-cable reference for 0.6/1 kV XLPE cables
24 Electrical XLPE volume resistivity at 20 °C ≥ 1 × 10¹² Ω·cm Material-level requirement (manufacturer reference)
25 Electrical Capacitance (approx., per core) ≤ 0.45 μF/km Manufacturer reference value
26 Electrical Reference ampacity — in air, 30 °C, both cores loaded ≈ 185 A Chengtantai two-core table (185 A Cu); Mingda armored YJV22 quotes 140 A @25 °C — derate per GB/T 16895 / IEC 60364
27 Electrical Reference ampacity — direct burial, 20 °C ≈ 231 A Chengtantai two-core table (231 A Cu); depends on soil thermal resistivity and depth
D. Thermal Performance
28 Thermal Max. continuous conductor temperature 90 °C XLPE insulation temperature class
29 Thermal Max. conductor temperature under short-circuit (≤ 5 s) 250 °C Per GB/T 12706.1 / IEC 60502-1
30 Thermal Ambient service temperature range -20 to +45 °C Per manufacturer datasheet family; check project specification
31 Thermal Min. installation (laying) temperature 0 °C Pre-heat the cable if ambient is below 0 °C
E. Flame Retardance (ZR)
32 Flame retardance Flame-retardant class ZC (class C) by default for "ZR" — GB/T 19666; ZA / ZB available on request; halogen-containing PVC (not LSZH)
33 Flame retardance Single-cable vertical flame-spread test Pass — GB/T 18380.12
34 Flame retardance Bunched flame-spread test (class C) Char extent ≤ 2.5 m above burner bottom edge — GB/T 18380.35: non-metallic volume ≥ 1.5 L/m; flame application 20 min
35 Flame retardance Halogen content Halogen-containing (PVC) — For low-smoke, zero-halogen requirement select WDZ-YJY (LSZH) type
F. Installation
36 Installation Min. bending radius — multi-core cable ≥ 15 × OD — GB 50168 practice for multi-core XLPE cables; OD = actual cable diameter
37 Installation Laying methods Conduit, tray, cable trench, duct, building trunking, supported/suspended aerial — Also direct burial with mechanical protection where permitted
38 Installation Site withstand test after installation DC 4U0 = 2.4 kV, 15 min (recommended) — Per utility procurement standard Q/GDW 13244.1-2018; practice may vary by project
G. Packing & Delivery
39 Packing Standard delivery length 100 m per coil/drum (or as ordered) — Typical industry practice; custom lengths available
40 Packing Cable marking Model, rated voltage, manufacturer, year of manufacture, sequential length marks — Per GB/T 6995 / project specification
41 Packing Packing form Coil (carton drum) / wooden drum / export packing — As per customer requirement



ZR-YJV 2×35 mm² — Test / Verification Parameters (per GB/T 12706.1 & IEC 60502-1)
Test Stage Test Item Method / Standard Requirement / Acceptance Criterion Notes
Routine test Conductor DC resistance measurement GB/T 3956 (IEC 60228) ≤ 0.524 Ω/km at 20 °C (per core) Measured on every production length
Routine test Power-frequency withstand voltage GB/T 12706.1 / IEC 60502-1 3.5 kV AC, 5 min, no breakdown Applied between each conductor and earth/water; 50 Hz
Routine test Construction check — insulation & sheath thickness, outer diameter GB/T 2951 Within GB/T 12706.1 tolerances Insulation ≥ 0.9 mm nominal; sheath ≥ 1.8 mm nominal
Sample test Hot set (thermal elongation) test — XLPE insulation GB/T 12706.1 §16.3.13 / GB/T 2951.11 200 ± 3 °C, 15 min, stress 0.2 MPa: elongation under load ≤ 175 %; permanent elongation after cooling ≤ 15 % Verifies degree of cross-linking
Sample test Conductor construction & diameter check GB/T 3956 Class 2; 7 × 2.52 mm; Ø ≈ 7.5 mm Sampled per batch
Type test Single-cable vertical flame-spread test (flame retardance) GB/T 18380.12 No flame spread; charring does not reach top reference point ZR / ZC flame-retardant property
Type test Bunched flame-spread test, class C GB/T 18380.35 Char extent ≤ 2.5 m above burner bottom edge; flame application 20 min; non-metallic volume ≥ 1.5 L/m Class ZC per GB/T 19666
Type test Bending test (mechanical) GB/T 12706.1 Bend around specified mandrel without insulation/sheath damage Mandrel diameter related to cable OD (multi-core)
Post-installation DC withstand test after installation Q/GDW 13244.1-2018 (recommended practice) 4U0 = 2.4 kV DC, 15 min, no breakdown For new installations; verify project specification
Optional Insulation resistance measurement at 20 °C Manufacturer test method ≥ 36.7 MΩ·km (typical finished-cable value) Not a routine item in GB/T 12706.1; confirm with factory
Optional XLPE volume resistivity at 20 °C Manufacturer / material test ≥ 1 × 10¹² Ω·cm Material-level reference



5. Fire Behaviour. Passes GB/T 18380.12 single burn and class-C bunched burn GB/T 18380.35 (char ≤ 2.5 m) → ZC per GB/T 19666. PVC contains halogen — WDZ-YJY for LSZH duty.



Technical Datasheet — Flame-Retardant (FR) Characteristics
ZR-YJV  0.6/1 kV  2 × 35 mm²  (Cu / XLPE / FR-PVC)
1.  Cable Identification
Code / Item Meaning / Value Standard / Note
ZR Flame Retardant (legacy prefix); under GB/T 19666-2019 defaults to Class C; modern equivalent = ZC GB/T 19666-2019
YJ XLPE — cross-linked polyethylene insulation —
V PVC outer sheath — flame-retardant grade, contains halogen (Cl) GB/T 19666-2019
0.6/1 kV Rated voltage U₀/U = 600/1000 V; maximum Uₘ = 1.2 kV IEC 60502-1
2 × 35 mm² Two cores, nominal copper conductor area 35 mm² per core (both cores equal) —
Construction Unarmoured, non-screened, round multi-core —
Application note Two-core → single-phase AC (L+N) or DC pair (+, −) —
2.  Flame-Retardant & Fire Performance  (CORE)
Property Value / Requirement Standard
Flame Retardant Class Class C (bundled cables, char length ≤ 2.5 m) GB/T 19666-2019; GB/T 18380.3 / IEC 60332-3-24
Legacy designation ZR (= ZC); modern prefix preferred: ZC GB/T 19666-2019
Test method — flame Bunched flame test (category C), char ≤ 2.5 m after flame removal GB/T 18380.3 (IEC 60332-3-24)
Halogen content Contains halogen — Cl from PVC sheath; releases HCl on burning GB/T 17650 / IEC 60754-1/-2
Smoke density Heavy dark smoke — NOT low-smoke (no LSZH certification) GB/T 17651 / IEC 61034
Corrosivity Corrosive — HCl gas generated during fire GB/T 17650 / IEC 60754-2
pH / conductivity of gases Not certified (PVC base — acidic / conductive combustion gases) GB/T 17650 / IEC 60754-2
Limited Oxygen Index (LOI) PVC typical ≈ 45–49 % O₂ (reference, design value) ASTM D2863 / GB/T 2406, reference
Max. conductor operating temp. 90 °C (long-term service) GB/T 12706.1-2020
Max. short-circuit temp. (≤5 s) 250 °C IEC 60502-1
Emergency overload temp. 105 °C (up to 130 °C transient) IEC 60502-1
Service ambient range (PVC sheath) −15 °C to +90 °C —
Min. installation ambient temp. 0 °C (pre-heat required below 0 °C) —
3.  Fire Test Summary
Test Requirement ZR-YJV 2×35 Verdict
Bunched flame test (Class C) Char length ≤ 2.5 m ✅ PASS (design, Class C)
Single flame test (IEC 60332-1) Self-extinguishing ✅ PASS (XLPE/PVC FR)
Smoke density (IEC 61034) Light transmittance ≥ 60 % for LSZH ❌ NOT applicable (PVC → heavy smoke)
Halogen content (IEC 60754) ≤ 0.5 % HCl for LSZH ❌ NOT applicable (contains Cl)
Acidity / corrosivity (IEC 60754-2) pH ≥ 4.3; conductivity ≤ 10 µS/mm for LSZH ❌ NOT certified (corrosive HCl)
Fire-survival (BS 6387 / IEC 60331) Circuit integrity during/after fire ❌ NOT applicable — use NH-ZR-YJV
4.  Key Electrical & Thermal Parameters
Parameter Value Note
Rated voltage U₀/U 0.6 / 1 kV Uₘ = 1.2 kV
Test voltage AC (5 min, routine) 3.5 kV IEC 60502-1
Type-test voltage 4.0 kV IEC 60502-1
DC resistance @ 20 °C (per core) ≤ 0.524 Ω/km GB/T 3956 / IEC 60228, Class 2 max
AC resistance @ 90 °C (est.) ≈ 0.681 Ω/km per core
Current rating — in air (30 °C, single circuit) ≈ 105–115 A (design ≈ 110 A) 2-core
Current rating — direct buried (20 °C, soil 1.0 K·m/W, 0.7 m) ≈ 130–145 A (design ≈ 138 A) 2-core
Short-circuit current (1 s, Cu, 250 °C, per core) ≈ 3.50 kA reference
Frequency 50/60 Hz AC (DC usable) —
Design recommendation: ≈ 110 A in air / ≈ 138 A buried, then apply grouping & ambient temperature correction. Buried rating > air rating due to better heat dissipation & different reference conditions.
5.  Construction & Material Specification
Layer (inside → out) Description / Specification FR Contribution
Conductor (×2) Bare annealed copper, Class 2 stranded, 7×∅2.52 mm, conductor Ø ≈ 7.5 mm None (Cu non-combustible)
Conductor screen Omitted (not required for 0.6/1 kV) —
Insulation (×2) XLPE, colours: red / black / blue etc., 0.9 mm nominal XLPE — low flame spread
Filler Flame-retardant PP / PE to form round assembly ✅ FR additive
Binder Flame-retardant tape over laid-up cores ✅ FR barrier
Outer sheath Flame-retardant PVC (ZR grade), 1.8 mm nominal, black ✅ Primary FR layer (halogenated)
Armour None —
Metallic screen None —
6.  Dimensional Data
Item Typical Value Remarks
Conductor nominal area (per core) 35 mm² —
Number of cores 2 —
Conductor construction Class 2, 7×∅2.52 mm min. 7 wires
Conductor diameter (approx.) 7.5 mm —
Insulation thickness 0.9 mm 35 mm² class
Diameter over insulated core 9.3 mm 7.5 + 2×0.9
Sheath thickness 1.8 mm multi-core rule, ≥ 1.8 mm
Overall cable diameter 20.5 – 21.5 mm (use 21.0 mm for design) —
Approx. weight 580 – 650 kg/km (use ≈ 615 kg/km) —
Cable shape Round —
7.  Mechanical & Installation Parameters
Parameter Value Note
Minimum bending radius (unarmoured multi-core) ≥ 15 × OD ≈ 315 mm @ Ø21.0 mm —
Max. pulling tension (Cu only) 50 N/mm² × 35 mm² × 2 = 3,500 N total use conductor sock, avoid sheath grip
Direct burial Allowed in non-aggressive soil; for mechanical protection use ZR-YJV22 2×35 —
Conduit ID ≥ 1.5 × OD → ≥ 32 mm (use 40 mm conduit) —
Elevation difference limit None (XLPE) —
8.  Selection Guide — When FR Matters
Scenario Recommended Cable Reason
Flame-retardant, halogenated acceptable (standard) ZR-YJV 2×35 (this cable) Class C FR, PVC sheath, cost-effective
Low-smoke halogen-free required (LSZH) WDZ-YJY 2×35 LSZH sheath — IEC 61034 / IEC 60754 compliant
Fire-survival circuit (circuit integrity) NH-ZR-YJV 2×35 BS 6387 / IEC 60331 fire-survival grade
Heavy mechanical load / direct burial risk ZR-YJV22 2×35 Steel-tape armoured version
Three-phase circuit 3 / 4 / 5-core version 2-core unsuitable for 3-phase



6. Verification. Routine: resistance, 3.5 kV/5 min, dimension audit (ins. ≥ 0.9 mm, sheath ≥ 1.8 mm). Sample: XLPE hot-set (200 ± 3 °C / 15 min / 0.2 MPa). Type: flame + bending. Site: DC 4U0 = 2.4 kV / 15 min (Q/GDW 13244.1-2018).



7.Cross Section Structure



2x35mm2 2 Cores Cable Stranded Copper Low Voltage Power Cable ZR Grade



ZR-YJV 2×35 mm² — Cable Cross-Section Structure (Schematic)
Two-core construction from conductor to outer sheath · nominal values per GB/T 12706.1 / IEC 60502-1 · not to exact scale

No. Layer Material / Construction Nominal Thickness (mm) Diameter (mm) Function / Remarks
1 Conductor (Cu) × 2 Annealed copper, Class 2 stranded — 7 × 2.52 mm per core (7/2.52), nominal 35 mm² per core — ≈ 7.5 (Ø per core) Current-carrying element; max DC resistance ≤ 0.524 Ω/km @ 20 °C (per core)
2 Insulation (XLPE) × 2 Cross-linked polyethylene 0.9 ≈ 9.3 (Ø per core, over insulation) Dielectric barrier; rated 90 °C continuous; withstands 3.5 kV / 5 min
3 Core lay-up Two insulated cores laid up with non-hygroscopic filler; optional binder tape — ≈ 18.6 (Ø over lay-up) Forms a round assembly for sheathing
4 Outer sheath (PVC) Flame-retardant PVC, ST2 type, black 1.8 ≈ 22.0 (Ø overall) Mechanical & moisture protection; flame retardance ZC (ZR) per GB/T 19666
Key Dimensions & Properties
Overall diameter 22.0 mm ahtk 22.0 (unarmored); armored YJV22 ≈ 24.9
Approx. cable weight ≈ 868 kg/km ahtk 868 (Al 413); armored YJV22 2×35 ≈ 1099 kg/km
Rated voltage 0.6/1 kV AC 50 Hz; max system voltage Um = 1.2 kV
Max conductor temperature 90 / 250 °C Continuous / short-circuit (≤ 5 s)
Min. bending radius (multi-core) ≥ 15 × OD — OD = actual cable diameter
Flame-retardant class ZC (ZR) — GB/T 19666



Product Structure Introduction — ZR-YJV 2×35 mm²
Two-core layered construction description, from conductor to outer sheath · per GB/T 12706.1 & IEC 60502-1 · CU / XLPE / PVC · 0.6/1 kV
1. Scope of the Document
This data sheet describes ZR-YJV 2×35, a flame-retardant two-core low-voltage feeder rated 0.6/1 kV AC, built on the copper / XLPE / PVC platform. It is made to GB/T 12706.1 / IEC 60502-1 with cores to GB/T 3956 / IEC 60228 and fire performance to GB/T 19666 (ZC default). Cable weight ≈ 868 kg/km and outside diameter ≈ 22.0 mm; standard 100 m lengths.
The two equal cores are intended to be loaded together; the cable is a fixed-installation product, not a flexible cord.
2. Conductor Layer
Each 35 mm² core is stranded from seven soft annealed copper wires of 2.52 mm (7/2.52), Class 2, to a nominal diameter of ≈ 7.5 mm. The maximum DC resistance is 0.524 Ω/km at 20 °C per core. At this size the conductor still pulls easily through conduit and trunking while delivering the 185 A class of capacity in air.
3. Insulation Layer
A 0.9 mm XLPE layer wraps every core, giving ≈ 9.3 mm over insulation. The cross-linked dielectric permits 90 °C continuous operation, 250 °C for five seconds on short-circuit, shows volume resistivity of at least 1×10¹² Ω·cm and survives the 3.5 kV / 5 min production voltage test.
4. Cabling & Jacket
The two insulated cores are laid together with non-hygroscopic packing and, usually, a binder tape, forming a round bundle of ≈ 18.6 mm. The 1.8 mm flame-retarded PVC (ST2) jacket closes the cable to ≈ 22.0 mm overall. Flame class ZC is demonstrated by GB/T 18380.12 and GB/T 18380.35; the PVC jacket is halogen-bearing, so use WDZ-YJY when zero-halogen is required.
5. Installation Guidance
• Route with a minimum bend radius of 15 × OD.  • Perform the post-installation DC test at 4U0 = 2.4 kV for 15 minutes.  • Service range −20 to +45 °C; warm reels before pulling below 0 °C.  • Ampacities here are whole-cable values — apply grouping, ambient and burial derating.  • Match gland and lug sizes to the ≈ 7.5 mm core diameter.



8.Insulation Test Data



Technical Datasheet — Insulation Test Data / ZR-YJV 0.6/1 kV  2×35 mm²
XLPE Insulated, Flame-Retardant PVC Sheathed Power Cable — Insulation Characteristics & Test Schedule

1.  Cable Identification
# Item Value Unit Standard / Reference Remarks
1 Cable designation ZR-YJV 0.6/1 kV 2×35 — GB/T 12706.1-2020 (IEC 60502-1) Unarmoured, non-screened, round
2 Conductor material Bare annealed copper — GB/T 3956 / IEC 60228 Class 2 stranded
3 Conductor construction 7 × Ø2.52 mm IEC 60228 min. 7 wires
4 Conductor nominal area (per core) 35 mm² GB/T 3956 Both cores 35 mm²
5 Number of cores 2 — — L+N (AC) or +/− (DC)
6 Insulation material XLPE (cross-linked polyethylene) — GB/T 12706.1-2020 Cross-linked polyethylene
7 Sheath material Flame-retardant PVC (ZR) — GB/T 19666-2019 Contains halogen (Cl)
8 Rated voltage U₀/U 0.6 / 1 kV IEC 60502-1 Uₘ = 1.2 kV

2.  Insulation Design Data
# Item Value Unit Standard / Reference Remarks
1 Insulation material XLPE — GB/T 12706.1-2020 Cross-linked polyethylene
2 Nominal insulation thickness 0.9 mm GB/T 12706.1-2020, Tab. 3 35 mm² class
3 Minimum insulation thickness (allowable) 0.71 mm GB/T 12706.1-2020 90% × 0.9 − 0.1 mm
4 Insulator colour (typical) Red / Black / Blue — GB/T 6995 / IEC 60227 Per phase / neutral
5 Diameter over insulated core 9.3 mm Calculated Conductor 7.5 + 2×0.9
6 Conductor diameter (approx.) 7.5 mm Calculated 7 × Ø2.52 mm
7 Volume resistivity @ 90 °C ≥ 10¹² Ω·cm GB/T 12706.1-2020 XLPE typical
8 Dielectric loss factor tan δ < 0.001 — IEC 60502-2 (ref.) XLPE, 20 °C, 50 Hz
9 Relative permittivity εᵣ 2.3 – 2.5 — Material data XLPE typical

3.  Thermal Characteristics of Insulation
# Item Value Unit Standard / Reference Remarks
1 Maximum conductor operating temp. (long-term) 90 °C GB/T 12706.1-2020 XLPE rated
2 Maximum short-circuit temp. (≤ 5 s) 250 °C IEC 60502-1 Copper conductor
3 Emergency overload temp. (short-term) 105 – 130 °C GB/T 12706.1-2020 Limited duration
4 Minimum installation ambient temp. 0 °C GB/T 12706.1-2020 Pre-heat below 0 °C
5 Service ambient range (PVC sheath) −15 to +90 °C GB/T 19666-2019 Sheath limit
6 Thermal stability (XLPE) Stable to ≥ 250 °C Material data Cross-linked

4.  Insulation Test Schedule (Routine / Type / Sample)
# Test Item Test Value / Condition Result Standard / Reference Remarks
1 Routine spark / withstand test (insulated core) 3.5 kV AC, 5 min PASS GB/T 12706.1-2020 / IEC 60502-1 Applied per core
2 Type test — AC withstand voltage 4.0 kV AC, 4 h PASS IEC 60502-1 After laying-up
3 Partial discharge test (type) ≤ 10 pC @ 1.73 U₀ PASS GB/T 12706.1-2020 / IEC 60502-1 XLPE, 1.73 kV
4 Insulation resistance (DC, 20 °C) ≥ 200 MΩ·km — GB/T 3048 / IEC 60060 Reference value
5 Volume resistivity @ 90 °C ≥ 10¹² Ω·cm PASS GB/T 12706.1-2020 Material check
6 Tangent delta (tan δ) — dielectric loss < 0.001 (20 °C, 50 Hz) PASS IEC 60502-2 (ref.) Low loss material
7 Hot-set test (cross-linking / XLPE) 200 °C, 15 min, load 20 N/cm² PASS IEC 60811-507 / GB/T 2951 Elongation / set
8 Aging in air (thermal endurance) 135 °C, 7 d (or per Arrhenius) PASS IEC 60811-401 / GB/T 2951 Tensile retained ≥ 80%
9 Tensile strength (XLPE insulation) ≥ 12.5 MPa MPa IEC 60811 / GB/T 2951 Before aging
10 Elongation at break (XLPE insulation) ≥ 200 % % IEC 60811 / GB/T 2951 Before aging
11 Cold bend test (insulation) −15 °C, 4 h, bend radius 5D No crack IEC 60811-404 / GB/T 2951 Applicable to PVC; XLPE no effect
12 Water absorption (XLPE, type) ≤ 10 mg / cm² mg/cm² IEC 60502-2 (ref.) Long-term moisture
13 Dielectric strength (breakdown voltage) ≥ 20 kV/mm (typical) kV/mm Material data XLPE intrinsic
14 Conductor DC resistance @ 20 °C ≤ 0.524 Ω/km Ω/km GB/T 3956 / IEC 60228 Class 2 copper, per core
15 Short-circuit current rating (1 s, 250 °C) ≈ 3.50 kA kA IEC 60364 / calculated Per core, reference

5.  Electrical Parameters (Derived from Insulation & Conductor)
# Parameter Value Unit Standard / Reference Remarks
1 Rated voltage U₀/U 0.6 / 1 kV IEC 60502-1 Uₘ = 1.2 kV
2 DC resistance @ 20 °C (per core) ≤ 0.524 Ω/km GB/T 3956 Class 2 copper
3 AC resistance @ 90 °C (est., per core) ≈ 0.681 Ω/km Calculated (α = 0.00393/K) R₂₀ × [1+α(90−20)]
4 Current rating — in air (30 °C, single circuit) ≈ 105 – 115 (design ≈ 110) A IEC 60287 / GB/T 16895 2-core, apply correction
5 Current rating — direct buried (20 °C, soil 1.0 K·m/W, 0.7 m) ≈ 130 – 145 (design ≈ 138) A IEC 60287 / GB/T 16895 2-core, apply correction
6 Test voltage AC (5 min, routine) 3.5 kV IEC 60502-1 Routine test
7 Type-test voltage 4.0 kV IEC 60502-1 Type test
8 Frequency 50 / 60 Hz AC (DC usable) Hz — —

6.  Dimensional / Inspection Result
# Item Design Value Measured (example) Tolerance Verdict
1 Conductor nominal area (per core) 35 mm² 35.0 mm² ± 0 % (nom.) OK
2 Number of wires 7 7 min. 7 OK
3 Wire diameter Ø2.52 mm Ø2.51 mm ± 1 % OK
4 Conductor diameter 7.5 mm 7.48 mm ± 2 % OK
5 Insulation thickness (nominal) 0.9 mm 0.92 mm −10 % + none OK
6 Minimum insulation thickness 0.71 mm 0.85 mm ≥ 0.71 mm OK
7 Diameter over insulated core 9.3 mm 9.32 mm ± 5 % OK
8 Overall cable diameter 20.5 – 21.5 (design 21.0) mm 21.1 mm ± 5 % OK
9 Sheath thickness 1.8 mm 1.82 mm −10 % + none OK
10 Approx. weight 580 – 650 (≈ 615) kg/km 618 kg/km ± 5 % OK

Notes
1. All insulation tests shall be carried out at (20 ± 5) °C and 45 – 75 % RH unless otherwise stated.
2. Routine test = 100 % production test; Type test = performed on representative samples; Sample test = per lot.
3. Test voltage 3.5 kV / 5 min is the routine withstand test per IEC 60502-1; 4.0 kV is the type-test voltage.
4. Values marked 'typical' or 'reference' are material / design values; confirm against the manufacturer's test report (TDS / CoC).
5. Current ratings are for a single circuit, unarmoured 2×35 mm²; apply correction factors for grouping, ambient temperature, soil thermal resistivity and depth.
6. XLPE insulation is rated 90 °C long-term / 250 °C short-circuit (≤ 5 s); do not exceed these limits in service.
7. For low-smoke halogen-free requirement → WDZ-YJY 2×35; for fire-survival circuits → NH-ZR-YJV 2×35; for heavy mechanical load → ZR-YJV22 2×35.
8. Standards: GB/T 12706.1-2020 (equiv. IEC 60502-1); GB/T 3956 / IEC 60228; GB/T 19666-2019; GB/T 2951 / IEC 60811; GB/T 3048.



9. Usage Cautions. Bend ≥ 15 × OD; avoid kinking and dragging over sharp edges; protect from UV; run the DC site test before energising; load both cores symmetrically; choose lugs sized for the ≈ 7.5 mm core.



2x35mm2 2 Cores Cable Stranded Copper Low Voltage Power Cable ZR Grade



9. Application Range. Single-phase feeders, L+N distribution, sub-boards, pump, HVAC and machine feeders at 0.6/1 kV — conduits, trays, trunking, trenches; indoor or sheltered outdoor.



2x35mm2 2 Cores Cable Stranded Copper Low Voltage Power Cable ZR Grade



10. Ordering Information. ZR-YJV 0.6/1 kV 2×35, length, coil/drum type, marking. Standard 100 m; confirm all figures against the factory certificate.



2x35mm2 2 Cores Cable Stranded Copper Low Voltage Power Cable ZR Grade
