Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)

Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)

Product Details

Place of Origin: China

Brand Name: Qifan

Certification: ISO9001, CCC, RoHS, SAA

Payment & Shipping Terms

Minimum Order Quantity: 100m

Price: usd3-8/meter

Packaging Details: wooden drumsPackaging Details Inner Packing: Wooden reel, Plastic reel, and Paper Reel Outer Packing: Carton box, Pull out box, Pallet available Other packing available according to clients' request

Delivery Time: 30-45days

Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram

Supply Ability: 50000K Meter/ per Month

Get Best Price

Product Details

Product Description
Highlight:
Model NO.:
SDI
Material Shape:
Round Wire
Range Of Application:
Flame Retardant
Brand:
QIFAN
QC:
200 Engineer
Warranty:
25 Years
Color:
Brown, White, Red. Green
Transport Package:
Reel Or Drum
Specification:
100m One Reel
Trademark:
Qifan
Origin:
China
HS Code:
8544492100
Supply Ability:
500000km Per Month
Type:
Insulated
Conductor Type:
Stranded
Application:
Underground
Conductor Material:
Copper
Sheath Material:
PVC
Insulation Material:
PVC
Model NO.:
SDI
Material Shape:
Round Wire
Range Of Application:
Flame Retardant
Brand:
QIFAN
QC:
200 Engineer
Warranty:
25 Years
Color:
Brown, White, Red. Green
Transport Package:
Reel Or Drum
Specification:
100m One Reel
Trademark:
Qifan
Origin:
China
HS Code:
8544492100
Supply Ability:
500000km Per Month
Type:
Insulated
Conductor Type:
Stranded
Application:
Underground
Conductor Material:
Copper
Sheath Material:
PVC
Insulation Material:
PVC
Fire Resistant 1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)

Product Description

PVC Sdi Cable, 450/750 V, 1/C, Australian Cu/V-90/PVC Power Cable (AS/NZS 5000.2)

Application: Fire Resistant - Mains and Sub-Mains, Fire Alarm Systems, Essential Services

Construction:
1.    Conductor - Plain annealed class 5 flexible copper
2.    Fire Resistant layer - Mica Tape
3.    Insulation - Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4.    Outer sheath - Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)

Cross Section:
1 core: 1.5~630mm2

Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC

Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min

Color:
Insulation: White or according to customer requirements
Sheath: Red or according to customer requirements

Standard:
Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)
Cond.
Area mm		 Stranding
No/mm		 Insulation
Thick mm		 Sheath
Thick mm		 Nom.O/D
mm		 Min. Installed
Bending
Radius mm		 Approx.
Mass Kg/Km		 Order
Now
1 1x1/1.13 0.6 0.8 4.1 20 30
1.5 1x7/0.50 0.6 0.8 4.5 20 40
2.5 1x7/0.67 0.7 0.8 5.2 25 55
4 1x7/0.85 0.8 0.9 6.2 25 80
6 1x7/1.04 0.8 0.9 6.8 30 100
10 1x7/1.35 1 0.9 8.2 35 145
16 1x7/1.70 1 1 9.4 40 225


Other sizes can also be produced as you required.
Size Conductor Strands Insulation Thickness
2x1.5mm2  7/0.52mm 0.6mm
2x2.5mm2 7/0.68mm 0.7mm
2x1.5mm2+1.5mm2 7/0.52mm 0.6mm
2x2.5mm2+2.5mm2 7/0.68mm 0.7mm
2x4mm2+2.5mm2 7/0.85mm+7/0.68mm 0.8mm
2x6mm2+2.5mm2 7/1.04mm+7/0.68mm 0.8m
------Our Feature------
  1. Imported equipment with experienced technical team
    The company have three plant and has 3048 employees which have 206 engineers. Plant has a series of imported production lines including Niehoff copper drawing lines, Troster Germany and Maillefer Finland 500KV VCV lines, stranding machine from Pourtier France, SKET Germany, Caballe Spain, 220KV and 35KV production line plus SIKORA X - RAY 8000 on-line eccentricity measuring unit from Germany
  2. Complete certification system
    Qifan Cable have gotten ISO 9001, ISO 14001, OHSAS 18001. Plant passed TUV, VDE, UL, CE, SAA, BS etc. certificate.
  3. Perfect Production system
    Qifan Cable products cover LV power cable, MV power cable, HV&EHV power cable, ABC cables, ACSR/AAC/AAAC/ACAR/OPGW ,submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, Lan cable, coaxial cable etc.
  4. Perfect Sales service system
    Qifan Cable can offer the OEM/ODM service, Multiple products, Skilled Export sale engineer team, Reasonable price, Reliable quality, Friendly service. Qifan is always your best choice.
1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)1.5mm SDI Single Core Double Insulated Electrical Wire 450/750V PVC/PVC (RED/WHITE)

Fang Yu (Shanghai) Automation Technology Co., Ltd. is a professional supplier of global intelligent building cable infrastructure products and services, and a trustworthy enterprise dedicated to global power development.

Fang Yu (Shanghai) Automation Technology Co., Ltd. provide you with more practical needs and better services. Fang Yu: Excellent quality, innovative services, global sharing.
