Copper Core PVC Coated Flexible Flat Electrical TPS Cable Wire
Application: Fire Resistant - Mains and Sub-Mains, Fire Alarm Systems, Essential Services
Construction:
1. Conductor - Plain annealed class 5 flexible copper
2. Fire Resistant layer - Mica Tape
3. Insulation - Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4. Filler - Flame retardant material
5. Binder Tape - Low smoke halogen-free flame retardant tape
6. Outer sheath - Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)
Cross Section:
2 core: 1.5~400mm2
3 core: 1.5~400mm2
4 core: 1.5~400mm2
5 core: 1.5~400mm2
2 core + earth: 1.5~400mm2
3 core + earth: 1.5~400mm2
4 core + earth: 1.5~400mm2
Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC
Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min
Color:
Insulation:
2 core: Red, Black
3 core: Red, White, Blue
4 core: Red, White, Blue, Black
5 core: Red, White, Blue, Black, Y/G
2 core + earth: Red, Black, Y/G
3 core + earth: Red, White, Blue, Y/G
4 core + earth: Red, White, Blue, Black, Y/G
Sheath: Red or according to customer requirements
Standard:
Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)
Other sizes can also be produced as you required.
| Size |
Conductor Strands |
Insulation Thickness |
| 2x1.5mm2 |
7/0.52mm |
0.6mm |
| 2x2.5mm2 |
7/0.68mm |
0.7mm |
| 2x1.5mm2+1.5mm2 |
7/0.52mm |
0.6mm |
| 2x2.5mm2+2.5mm2 |
7/0.68mm |
0.7mm |
| 2x4mm2+2.5mm2 |
7/0.85mm+7/0.68mm |
0.8mm |
| 2x6mm2+2.5mm2 |
7/1.04mm+7/0.68mm |
0.8m |
------Our Feature------
- Imported equipment with experienced technical team
The company have three plant and has 3048 employees which have 206 engineers. Plant has a series of imported production lines including Niehoff copper drawing lines, Troster Germany and Maillefer Finland 500KV VCV lines, stranding machine from Pourtier France, SKET Germany, Caballe Spain, 220KV and 35KV production line plus SIKORA X - RAY 8000 on-line eccentricity measuring unit from Germany
- Complete certification system
Qifan Cable have gotten ISO 9001, ISO 14001, OHSAS 18001. Plant passed TUV, VDE, UL, CE, SAA, BS etc. certificate.
- Perfect Production system
Qifan Cable products cover LV power cable, MV power cable, HV&EHV power cable, ABC cables, ACSR/AAC/AAAC/ACAR/OPGW ,submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, Lan cable, coaxial cable etc.
- Perfect Sales service system
Qifan Cable can offer the OEM/ODM service, Multiple products, Skilled Export sale engineer team, Reasonable price, Reliable quality, Friendly service. Qifan is always your best choice.
Quality Control
From the choice of copper wire, insulation and sheath materials, we put quality in the first place.
Using 99.9% oxygen-free copper as conductor raw material.
Insulation and sheathing materials in accordance with national standards.
Production is first controlled by professional technicians.Reduce the error to +-1%.
After the production is completed, the factory quality inspection sampling inspection, each batch of products complete the factory inspection and resale.
Our customers
Our company is committed to the development and maintenance of global market.And we have over 10 years exporting experience.Over decades of development of international market,we have built up,maintained and improved business relationship with clients from East Asia,Southeast Asia,Middle East,South and North America and Europe.
Welcome to our factory anytime!
PVC Coated: The conductors are coated with PVC (Polyvinyl Chloride), which provides electrical insulation and protection for the copper cores. PVC coating also offers resistance against moisture, chemicals, and mechanical damage.
