BVR 2.5 mm² / 14 AWG Copper Conductor PVC Insulated Flexible Building Wire

Product Overview

The BVR 2.5 mm² (14 AWG)​ is a single-core, fine-strand annealed copper building wire​ with PVC insulation, engineered for installations that demand superior flexibility without sacrificing current-carrying capacity. Compliant with GB/T 5023.3-2008​ and JB/T 8734.2-2016, and backed by CCC certification, it is the workhorse flexible wire for electricians and OEMs who need a wire that bends easily around tight corners, survives panel vibration, and terminates cleanly in crowded enclosures.

Performance Highlights

Electrical Performance

• 450/750 V Rating​ — Covers the full range of low-voltage building distribution: single-phase 230 V lighting and socket circuits, three-phase 400 V sub-feeds, and 24–48 V control loops.

• Class 5 Stranding = Low I²R Loss​ — With a certified ≤ 7.41 Ω/km at 20 °C, the multi-strand copper core keeps voltage drop within 3% over runs up to ~25 m at full 20 A load — critical for socket circuits where appliance performance depends on delivered voltage.

• 2000 V AC / 5 min Withstand​ — Every reel-length batch is subjected to high-voltage proof testing; the PVC dielectric routinely exceeds the 2000 V threshold, confirming zero pinholes or thin spots in the insulation wall.

• Insulation Resistance ≥ 0.011 MΩ·km @ 70 °C​ — Translates to a leakage current of less than 0.1 mA per 100 m at rated temperature, well within safety margins for fixed building wiring.

Thermal & Current-Carrying Capability

• Thermal Class: 70 °C​ — The PVC compound is stabilized for continuous operation at 70 °C conductor temperature. Short-circuit rating: 160 °C for up to 5 seconds, accommodating typical MCB response times without insulation melting or flowing.

• Ampacity by Installation Scenario:

*Values derived from GB/T 16895.15 and IEC 60364-5-52 reference methods; apply local correction factors for ambient >30 °C or grouped circuits.

• Thermal Cycling Stability​ — The fine-strand construction distributes thermal expansion evenly across strands, reducing the risk of localized hot spots at termination points — a known failure mode in solid wires subjected to load cycling.

Mechanical Durability

• Class 5 Fine-Strand Design​ — Typically 50 strands of 0.25 mm​ (or equivalent lay), producing a conductor that can withstand >20,000 bend cycles​ at 2× diameter without strand breakage (per IEC 60227 flex test methodology). This makes BVR the correct choice for connections subject to building settlement, equipment vibration, or periodic re-routing.

• Tight-Corner Routing​ — The flexible core navigates 90° conduit sweeps and crowded DIN-rail enclosures where a solid 2.5 mm² conductor would be difficult or impossible to position cleanly. Minimum bend radius: 4× overall diameter (~17 mm).

• Insulation Toughness​ — 0.8 mm PVC wall maintains integrity under ≥ 150 N/cm compressive force​ (simulated conduit crush test) and resists nicking from fish-tape abrasion during pulls. Average OD ≤ 4.2 mm.

• Termination Reliability​ — Stranded copper cold-flows less than solid under screw pressure, maintaining clamp force over thermal cycles. When paired with bootlace ferrules, the connection resistance remains stable for the life of the installation.

Safety Characteristics

• Flame Retardant​ — Self-extinguishing per GB/T 18380.1​ single-vertical test; flame spread limited to <50 mm from the top clamp after 60 s ignition.

• Color Range​ — Red, Black, Blue, Yellow/Green, White, Brown, Grey, Orange for code-compliant circuit identification.

• Non-Wicking Insulation​ — Tight extrusion prevents capillary moisture ingress along the conductor-insulation interface in high-humidity environments.

Environmental & Chemical Resistance

• Indoor Use (Dry to Damp)​ — Not rated for immersion or continuous outdoor UV exposure.

• Chemical Resistance​ — Unaffected by dilute acids, alkalis, alcohols, and most cleaning agents at room temperature.

• Service Life​ — 25+ years at ≤70 °C conductor temperature; derate accordingly in high-ambient or grouped installations.

Color Selection

Installation & Handling

Application Scope

Primary Applications:

• Final sub-circuits to socket outlets and switched loads

• Distribution board internal links and busbar connections

• Control cabinet wiring (DIN-rail equipment, contactors, relays)

• HVAC terminal units, fan coil connections, small pump feeds

• OEM machinery internal harnesses and equipment power entry

Typical Projects:

• Residential new-build and rewire (socket rings, radial circuits)

• Commercial fit-outs (partition power, modular office systems)

• Light industrial control panels and automation enclosures

• Public building electrical infrastructure (schools, clinics, municipal facilities)

Product Selection Guide

Quality Assurance

Every production batch undergoes in-process and final inspection covering:

• Conductor resistance measurement (4-wire Kelvin method)

• Strand count verification and lay-length audit

• Insulation thickness and concentricity check (optical micrometer)

• High-voltage spark test (100% length, 3000 V AC)

• Flame retardancy sampling (vertical single-cable)

• Dimensional and visual inspection

Test reports and Certificate of Compliance (CoC)​ are available upon request, referencing batch number and manufacturing date.

Summary

The BVR 2.5 mm² / 14 AWG​ flexible building wire is the electrician's choice when installation geometry demands a wire that routes cleanly, bends without fighting back, and terminates without strand splay. Its Class 5 fine-strand copper core delivers the same ampacity as a solid conductor but with installation flexibility that saves time on every pull and every panel dress. For projects requiring enhanced fire safety or low-smoke performance, direct upgrade paths exist within the same manufacturer's WDZ, NH, and BYJ​ families — ask for flexible-strand options.
