Two Layer PVC Insulation Electrical Cable Wire Single Core Stranded Copper
Single Core Stranded copper Two Layer PVC Insulation Electrical Cable Wire
Description:
Stranded Copper, Cl.2, PVC Insulation
As per standard IEC 60227 IEC 60228 GB/T5023-2008
Constructions
Conductor: Stranded copper conductor, conforms to IEC 60228 class 1or class 2
Insulation : PVC compound rated 70ºC or 85ºC for continuous operation.
Note: Insulation color as per standards or customer requirement
Applications
Used for indoor applications for electric power, lighting and internal wiring in houses.
Standards
International: IEC 60227 IEC 60331, IEC 61034
China: GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001
Other standards such as BS,DIN and ICEA upon request
Technical data
Rated voltage:300/500 V, 300/300V, 450/750V
Max. Conductor Temp. in normal use: 70°C or 90°C
Certificates
CE, RoHS, CCC, KEMA and more others at request
Packing:
Wooden iron Drums
| Type |
Name |
Laying Site and Requirements |
Long-time Permissible Working Temperature of Conductor(ºC) |
| 227IEC01/05 BV BLV |
Copper Conductor,PVC Insulated Wire |
Fixed laid in the circumstance of indoor, conduit etc. |
70 |
| Aluminium Conductor,PVC Insulated Wire |
| 227IEC 07 BV-90 |
Heat Resistant Copper Conductor,PVC Insulated Wire at 90ºC |
Fixed laid in the circumstance of high temperature environment and can be laid indoor, conduit etc. |
90 |
| BVR |
Copper Conductor,PVC Insulated Flexible Wire |
Fixed laid where flexibility is required. |
70 |
| 227-IEC10 BVV |
Copper Conductor PVC Insulated and PVC Sheathed Round Wire |
Fixed laid where high mechanical protection and moisture are required. They can be laid in the air or underground. |
70 |
| BLVV |
Aluminium Conductor PVC Insulated and PVC Sheathed Round Wire |
| BVVB |
Copper Conductor PVC Insulated and PVC Sheathed Flat Wire |
| BLVVB |
Aluminium Conductor PVC Insulated and PVC Sheathed Flat Wire |
| 227IEC 02 RV227 IEC 06 RV |
Copper Conductor,PVC Insulated Flexible Connector |
Mainly used at middle-light type movable euipments, instrument and meters, household appliances, power and lighting and the places where flexibility is required. |
70 |
| 227IEC 42 RVB |
Copper Conductor,PVC Insulated Flat Flexible Connector |
| RVS |
Copper Conductor,PVC Insulated Flexible Twisting Connector |
| 227IEC52 RVV 227IEC53 RVV |
Copper Conductor PVC Insulated and PVC Sheathed Round Flexible Connector(Light and Common Type) |
------Our Feature------
- Imported equipment with experienced technical team
The company have three plant and has 3048 employees which have 206 engineers. Plant has a series of imported production lines including Niehoff copper drawing lines, Troster Germany and Maillefer Finland 500KV VCV lines, stranding machine from Pourtier France, SKET Germany, Caballe Spain, 220KV and 35KV production line plus SIKORA X - RAY 8000 on-line eccentricity measuring unit from Germany
- Complete certification system
Qifan Cable have gotten ISO 9001, ISO 14001, OHSAS 18001. Plant passed TUV, VDE, UL, CE, SAA, BS etc. certificate.
- Perfect Production system
Qifan Cable products cover LV power cable, MV power cable, HV&EHV power cable, ABC cables, ACSR/AAC/AAAC/ACAR/OPGW ,submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, Lan cable, coaxial cable etc.
- Perfect Sales service system
Qifan Cable can offer the OEM/ODM service, Multiple products, Skilled Export sale engineer team, Reasonable price, Reliable quality, Friendly service. Qifan is always your best choice.
Fang Yu (Shanghai) Automation Technology Co., Ltd. Cable has passed ISO9001 quality management system certification, ISO14001 environmental management system certification, ISO45001 occupational health and safety management system certification, ISO50001 energy management system certification, and two integration management system certification. It has also received the title of national green factory.
Fang Yu (Shanghai) products have passed China Compulsory Certification (CCC), coal mine product safety mark certification, China Classification Society certification, Telus certification, German TUV certification, European Union CE certification, and United States UL certification.
