Low Voltage Power Cable AS/NZS 5000.2 SDI Wire low voltage electrical cable

Name: Low Voltage Power Cable AS/NZS 5000.2 SDI Wire low voltage electrical cable
Brand: Qifan
SKU: Qifan
Price: 3 USD
Availability: InStock
Rating: 5 (110 reviews)

Product Details

Place of Origin: China

Brand Name: Qifan

Certification: ISO9001, CE, CCC, SAA

Payment & Shipping Terms

Minimum Order Quantity: 100m

Price: usd3-8/meter

Packaging Details: wooden drumsPackaging Details Inner Packing: Wooden reel, Plastic reel, and Paper Reel Outer Packing: Carton box, Pull out box, Pallet available Other packing available according to clients' request

Delivery Time: 30-45days

Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram

Supply Ability: 50000K Meter/ per Month

Get Best Price

Product Details

Product Description

Highlight:

Model NO.:	SAA Cable	Material Shape:	Round Wire
Range Of Application:	Flame Retardant	Brand:	QIFAN
Quality:	ISO SAA	Stuff:	3800
Color:	Red	Transport Package:	Wooden Drums
Specification:	Copper Cable	Trademark:	Qifan
Origin:	China	HS Code:	8544492100
Supply Ability:	5000000000km	Type:	Insulated
Conductor Type:	Stranded	Application:	Overhead, Underground
Conductor Material:	Copper	Sheath Material:	PVC
Insulation Material:	PVC	Samples:	US$ 0/Piece 1 Piece(Min.Order) \| Request Sample

Model NO.:	SAA Cable
Material Shape:	Round Wire
Range Of Application:	Flame Retardant
Brand:	QIFAN
Quality:	ISO SAA
Stuff:	3800
Color:	Red
Transport Package:	Wooden Drums
Specification:	Copper Cable
Trademark:	Qifan
Origin:	China
HS Code:	8544492100
Supply Ability:	5000000000km
Type:	Insulated
Conductor Type:	Stranded
Application:	Overhead, Underground
Conductor Material:	Copper
Sheath Material:	PVC
Insulation Material:	PVC
Samples:	US$ 0/Piece 1 Piece(Min.Order) \| Request Sample

Low Voltage Power Cable AS/NZS 5000.2 SDI Wire low voltage electrical cable

Product Description

AS/NZS 5000.2 450/750V 1C CU/PVC/PVC SDI Wire 1mm2 1.5mm2 2.5mm2 4mm2 6mm2 10mm2 16mm2

Application: Fire Resistant - Mains and Sub-Mains, Fire Alarm Systems, Essential Services

Construction:
1.    Conductor - Plain annealed class 2 /5 flexible copper
2.    Fire Resistant layer - Mica Tape
3.    Insulation - Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4.    Outer sheath - Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)

Cross Section:
1 core: 1.5~630mm2

Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC

Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min

Color:
Insulation: White or according to customer requirements
Sheath: Red or according to customer requirements

Standard:
Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)

Cond. Area mm	Stranding No/mm	Insulation Thick mm	Sheath Thick mm	Nom.O/D mm	Min. Installed Bending Radius mm	Approx. Mass Kg/Km	Order Now
1	1x1/1.13	0.6	0.8	4.1	20	30
1.5	1x7/0.50	0.6	0.8	4.5	20	40
2.5	1x7/0.67	0.7	0.8	5.2	25	55
4	1x7/0.85	0.8	0.9	6.2	25	80
6	1x7/1.04	0.8	0.9	6.8	30	100
10	1x7/1.35	1	0.9	8.2	35	145
16	1x7/1.70	1	1	9.4	40	225

Other sizes can also be produced as you required.

Size	Conductor Strands	Insulation Thickness
2x1.5mm2	7/0.52mm	0.6mm
2x2.5mm2	7/0.68mm	0.7mm
2x1.5mm2+1.5mm2	7/0.52mm	0.6mm
2x2.5mm2+2.5mm2	7/0.68mm	0.7mm
2x4mm2+2.5mm2	7/0.85mm+7/0.68mm	0.8mm
2x6mm2+2.5mm2	7/1.04mm+7/0.68mm	0.8m

AS/NZS 5000.2 450/750V 1c Cu/PVC/PVC SDI Wire 1mm2 1.5mm2 2.5mm2 4mm2 6mm2 10mm2 16mm2

Fang Yu (Shanghai) Automation Technology Co., Ltd. Our products are widely used in water conservancy, electricity, home decoration, rail transit, construction engineering, aerospace, new energy, communication, intelligent equipment, offshore engineering, and mining and other fields.

Fang Yu (Shanghai) Automation Technology Co., Ltd. Cable has passed ISO9001 quality management system certification, ISO14001 environmental management system certification, ISO45001 occupational health and safety management system certification, ISO50001 energy management system certification, and two integration management system certification. It has also received the title of national green factory.
