Product Details
Place of Origin: China
Brand Name: Qifan
Certification: ISO9001, CE, CCC
Model Number: THHN
Payment & Shipping Terms
Minimum Order Quantity: 100m
Price: usd3-8/meter
Packaging Details: wooden drumsPackaging Details Inner Packing: Wooden reel, Plastic reel, and Paper Reel Outer Packing: Carton box, Pull out box, Pallet available Other packing available according to clients' request
Delivery Time: 30-45days
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 50000K Meter/ per Month
Model NO.: |
THHN |
Material Shape: |
Round Wire |
Range Of Application: |
Flame Retardant |
Brand: |
QIFAN |
QC Team: |
200 |
Color: |
Black Red Yellow Green Blue |
Standards: |
UL83 |
Transport Package: |
Coils |
Specification: |
Copper Wire |
Trademark: |
QF |
Origin: |
China |
HS Code: |
8544492100 |
Supply Ability: |
5000000000km |
Type: |
Insulated |
Conductor Type: |
Stranded |
Application: |
Underground |
Conductor Material: |
Copper |
Sheath Material: |
Nylon |
Insulation Material: |
PVC |
Samples: |
US$ 0/Meter 1 Meter(Min.Order) | Request Sample |
Model NO.: |
THHN |
Material Shape: |
Round Wire |
Range Of Application: |
Flame Retardant |
Brand: |
QIFAN |
QC Team: |
200 |
Color: |
Black Red Yellow Green Blue |
Standards: |
UL83 |
Transport Package: |
Coils |
Specification: |
Copper Wire |
Trademark: |
QF |
Origin: |
China |
HS Code: |
8544492100 |
Supply Ability: |
5000000000km |
Type: |
Insulated |
Conductor Type: |
Stranded |
Application: |
Underground |
Conductor Material: |
Copper |
Sheath Material: |
Nylon |
Insulation Material: |
PVC |
Samples: |
US$ 0/Meter 1 Meter(Min.Order) | Request Sample |
UL listed THHN or THWN-2 Electrical wire Cable
1 Standard:
ul83.
2.Construction:
Conductor: Annealed Copper, solid or stranded sizes 14AWG up to 1000MCM
Insulation: Premium Grade Flame Retardant Polyvinyl Chloride( PVC)
Jacket: Tough Polyamide (Nylon)
3 Applications
General purpose building wire for services, feeders and branch circuits.
Temperature rating not to exceed:
THHN/THWN: 90°C dry and dump, 600V
THHN/THWN: 75 °C wet or in oil, 600V
THWN-2: 90°C Dry, wet or in oil,600V
4. Standard&Test Specification:
THHN/THWN-2 Conforms to following standards:
UL83 for Thermoplastic Insulated Wire and Cables(THHN/THWN-2)
5 Specification of Thhn cable:
|
Size |
Section |
Cu Cond. |
Cond Dia. |
PVC Thick |
Nylon Thick |
OD |
|
AWG /MCM |
Mm2 |
Wire no./mm |
mm |
mm |
mm |
mm |
|
14 |
2.08 |
1/1.63 |
1.63 |
0.38 |
0.1 |
2.59 |
|
12 |
3.31 |
1/2.05 |
2.05 |
0.38 |
0.1 |
3.01 |
|
10 |
5.26 |
1/2.59 |
2.59 |
0.51 |
0.1 |
3.81 |
|
14 |
2.08 |
19/0.38 |
1.9 |
0.38 |
0.1 |
2.86 |
|
12 |
3.31 |
19/0.47 |
2.35 |
0.38 |
0.1 |
3.31 |
|
10 |
5.26 |
19/0.6 |
3.00 |
0.51 |
0.1 |
4.22 |
|
8 |
8.37 |
19/0.75 |
3.75 |
0.76 |
0.13 |
5.53 |
|
6 |
13.3 |
19/0.95 |
4.75 |
0.76 |
0.13 |
6.53 |
|
4 |
21.2 |
19/1.19 |
5.95 |
1.02 |
0.15 |
8.29 |
|
3 |
26.7 |
19/1.33 |
6.65 |
1.02 |
0.15 |
8.99 |
|
2 |
33.6 |
19/1.5 |
7.5 |
1.02 |
0.15 |
9.84 |
|
1 |
42.4 |
19/1.68 |
8.4 |
1.27 |
0.18 |
11.3 |
|
1/0 |
53.5 |
19/1.89 |
9.45 |
1.27 |
0.18 |
12.35 |
|
2/0 |
67.4 |
19/2.12 |
10.6 |
1.27 |
0.18 |
13.5 |
|
3/0 |
85 |
19/2.38 |
11.9 |
1.27 |
0.18 |
14.8 |
|
4/0 |
107 |
19/2.67 |
13.35 |
1.27 |
0.18 |
16.25 |
|
250 |
127 |
37/2.09 |
14.63 |
1.52 |
0.2 |
18.07 |
|
300 |
152 |
37/2.29 |
16.03 |
1.52 |
0.2 |
19.47 |
|
350 |
177 |
37/2.47 |
17.29 |
1.52 |
0.2 |
20.73 |
|
400 |
203 |
37/2.64 |
18.48 |
1.52 |
0.2 |
21.92 |
|
500 |
253 |
37/2.95 |
20.65 |
1.52 |
0.2 |
24.09 |
|
600 |
304 |
61/2.52 |
22.68 |
1.78 |
0.23 |
26.70 |
|
750 |
380 |
61/2.82 |
25.38 |
1.78 |
0.23 |
29.40 |
|
1000 |
507 |
61/3.25 |
29.25 |
1.78 |
0.23 |
33.27
|
Qifan's products have been exported to more than 30 countries around the world, widely used in the fields of infrastructure, utilities, resources, construction, renewable energy, petrochemical etc.
Quick response and good customer service, short lead time are our focus. With our experience, quality, dedication, innovation, Qifan cable is your right choice for all your cable need.
Qifan Cable-make pioneering efforts and forge ahead!
